Australia hot Sale 1P+N 4.5kA 16amp Elcb RCBO Rcd Residual Circuit Breaker 30mA SJVL6-32 CB Certification
- Share
- Issue Time
- 2019/10/18
Summary
Provides protection against earth fault/leakage current, short-circuit and overload
High short-circuit capacity
Provides complementary protection against direct contact by human body.
Effectively protects electric equipment against insulating failure
Contact position indication
Provides protection against over-voltage
Provides comprehensive protection to household and commercial distribution
systems.

Construction and Feature
Provides protection against earth fault/leakage current, short-circuit and overload
High short-circuit capacity
Provides complementary protection against direct contact by human body.
Effectively protects electric equipment against insulating failure
Contact position indication
Provides protection against over-voltage
Provides comprehensive protection to household and commercial distribution
systems.
Technical Data
Type: Electronic type
Residual current characteristics: AC
Pole No.: 1P+N
Tripping curve: B, C, D
Rated short-circuit capacity: 4.5kA
Rated current (A): 6, 10, 16, 20, 25, 32
Rated voltage: 240V AC
Rated frequency: 50/60Hz
Rated residual operating current(mA): 0.03, 0.1, 0.3
Tripping duration: instantaneous≤0.1s
Electro-mechanical endurance: 4000 cycles
Connection terminal: pillar terminal with clamp
Terminal Connection Height: H1=16mm H2=21mm
Over-voltage tripping: 280V±5%
Technical Data
S2 Shunt Tripper
U2+O2 Over-voltage and under-voltage tripper
Connection capacity:
Flexible conductor 10mm²
Rigid conductor 16mm²
Installation:
On symmetrical DIN rail 35.5mm
Panel mounting
Overall & Installation Dimensions

Wiring Diagram
